138-7402: Flywheel Housing Cover Plate Bolt

Product Photos

138-7402: Flywheel Housing Cover Plate Bolt 1387402 buy
Price Имеет замену, оставьте запрос
Lead Time on request

Key Details

OEM / Part No.138-7402
ManufacturerCaterpillar
CategoryFasteners
Country of OriginOrigin on request
Weight—
Dimensions—
Unit of Measurepcs
ConditionNew original part

Product Description

138-7402 Caterpillar Flywheel Housing Cover Plate Bolt is made of Carbon Steel,Alloy Zinc. The specified material for this part is Carbon Steel,Alloy Zinc.

Specifications

MaterialУглеродистая сталь,Цинковый сплав
Thread Size (in)0
Thread Size (mm)M10
Thread Size Dia X Pitch (mm)M10x1.5
CoatingZinc
Bolt Length (mm)50,0
Grip Length (in)0,945
Bolt Length (in)1.969
Grip Length (mm)24,0
Class Or GradeISO 898-1 Class 8.8
Bolt TypeHex Head
Hand Of ThreadRH
Locking FeatureCaptive Lockwasher

Delivery & Payment

Отгрузка

Pickup from the supplier's warehouse in Shenzhen, China, or in Moscow, Russia.

Оплата

Payment in Chinese yuan (CNY) to our company bank account in China, or in Russian rubles (RUB) to the Russian company bank account.

Warranty

This page is ready for discovery and quote requests; commercial terms are confirmed by a manager.

Compatible Models

Industrial Engine3024, C2.2, 3024C
Гидравлический мини-экскаватор304.5
Мини-погрузчик242B, 232B, 226B, 216B, 216, 228, 226, 232, 242
Генераторные установкиC2.2
Компактный колесный погрузчик902
Погрузчик повышенной проходимости257B, 247B
