Caterpillar
216-9688: LINKAGE PIN 100 MM X 662 MM (3.94 IN X 26.06 IN)Price¥24281
Lead timeTBC
Availability:ChinaRest
330-9680: LINKAGE PIN 45 MM X 194 MM (1.77 IN X 7.64 IN)
Product Photos
Price
¥1437
Lead Time
35 days
Availability:ChinaRest
Key Details
| OEM / Part No. | 330-9680 |
|---|---|
| Manufacturer | Caterpillar |
| Category | Linkage Pins |
| Country of Origin | Origin on request |
| Weight | 2.5 kg |
| Dimensions | 0.206 Х 0.053 Х 0.053 |
| Unit of Measure | pcs |
| Condition | New original part |
Product Description
330-9680 Caterpillar LINKAGE PIN 45 MM X 194 MM (1.77 IN X 7.64 IN) is made of STEEL,Alloy Zinc,Carbon Steel. The specified material for this part is STEEL,Alloy Zinc,Carbon Steel.
Specifications
| Pin Type | Straight Pin |
|---|---|
| Material | STEEL,Alloy Zinc,Carbon Steel |
| Plating | Zinc |
| Pin Diameter (mm) | 45,0 |
| Pin Diameter (in) | 1,77 |
| Length (mm) | 194,0 |
| Length (in) | 7,64 |
| Removal Aid / Feature | No Puller Hole |
| Groove Width (mm) | 3.1 |
| Groove Diameter (mm) | 42.1 |
| Groove Width (in) | 0.122 |
| Effective Length (in) | 6,85 |
| Outside Diameter (in) | 1,772 |
| Groove Diameter (in) | 1.657 |
| Effective Length (mm) | 174,0 |
| Outside Diameter (mm) | 45,0 |
| Puller Thread | No |
| Internal Grease Passage Hole | No |
Delivery & Payment
Отгрузка
Pickup from the supplier's warehouse in Shenzhen, China, or in Moscow, Russia.
Оплата
Payment in Chinese yuan (CNY) to our company bank account in China, or in Russian rubles (RUB) to the Russian company bank account.
Warranty
Warranty and delivery terms are confirmed on request.
Compatible Models
Экскаватор-погрузчик434E, 444E
