383-6956: Carrier Roller Assembly

Product Photos

383-6956: Carrier Roller Assembly 3836956 buy
Price Price on request
Lead Time —

Key Details

OEM / Part No.383-6956
ManufacturerCaterpillar
CategoryCarrier Roller Rim Assemblies
Country of OriginOrigin on request
Weight—
Dimensions—
Unit of Measurepcs
ConditionNew original part

Product Description

383-6956 Caterpillar Carrier Roller Assembly is listed in the Carrier Roller Rim Assemblies category. Use the exact part number to verify fitment, specifications, and current availability before ordering.

Specifications

Tread Diameter (in)3,346
Undercarriage Width (mm)94,0
Flange TypeОдинарный фланец
Flange Diameter (in)4,134
Diameter (mm)105,0
Tread Diameter (mm)85,0
Flange Diameter (mm)105,0
Gage Diameter (in)2,091
Flange Thickness (in)0,346
Tread Width (mm)25.3
Width (in)3,701
Tread Width (in)0.996
Width (mm)94,0
Bore Diameter (mm)42,0
Inside Spread (mm)43.4
Oil HoleNo
Inside Spread (in)1.709
Bearing Inner Diameter (in)1.181
Bore Diameter (in)1,654
Bearing Inner Diameter (mm)30
Flange Thickness (mm)8,8
MaterialDuctile (Spheroidal) Iron
Gage Diameter (mm)53,12

Delivery & Payment

Отгрузка

Pickup from the supplier's warehouse in Shenzhen, China, or in Moscow, Russia.

Оплата

Payment in Chinese yuan (CNY) to our company bank account in China, or in Russian rubles (RUB) to the Russian company bank account.

Warranty

Warranty and delivery terms are confirmed on request.

Compatible Models

Гидравлический мини-экскаватор308E CR, 308E SR, 308E2CR, 308E2SR, 308E, 308E2 CR, 308E2 SR
