6F-6672: 17.12mm Inner Diameter Seal O Ring

Product Photos

Photo pending

Price ¥13

Lead Time 5 days

Availability:ChinaRest

Key Details

OEM / Part No.	6F-6672
Manufacturer	Caterpillar
Category	O-Rings
Country of Origin	Origin on request
Weight	0.01 kg
Dimensions	—
Unit of Measure	pcs
Compatibility
Condition	New original part

Product Description

Description: O-Rings are used in static sealing and some dynamic applications. Attributes: Cat® O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in Cat engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set. In addition, certain Cat O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation. Dimensions of our O-Rings are consistently held to tight tolerances to ensure they fit properly into seal grooves with the necessary seal compression. With over 2500 O-Rings in different sizes and materials, Cat O-Rings are your best solution for your Cat and other mobile equipment O-Ring needs. Cat Sealing systems protect more expensive parts from leaks and contamination. Protect your investment with Genuine Cat Seals. Applications: O-Rings are used in many static and dynamic joints throughout Cat machines and engines.

Specifications

Cross Section Diameter (mm)	2,62
Cross Section Diameter (in)	0,103
Inside Diameter (mm)	17,12
Inside Diameter (in)	0,674
Material	NBR — нитрил,Нитрилкаучук (NBR) (75),Нитрилкаучук (NBR),Каучук из нитрила (NBR / HNBR / XNBR)
Dash Size (in)	115
Material Hardness	75A
Polymer	NBR (Nitrile butadiene)

Delivery & Payment

Отгрузка

Pickup from the supplier's warehouse in Shenzhen, China, or in Moscow, Russia.

Оплата

Payment in Chinese yuan (CNY) to our company bank account in China, or in Russian rubles (RUB) to the Russian company bank account.

Warranty

Warranty and delivery terms are confirmed on request.

Compatible Models

Судовой двигатель3304, 3306, D353E, D353C, D353D, D330A, D330C, D397D, D375D, 3406B, 3406C, D337F, D333A, D333C, 3208, D364, D337, D326F, 3306B, 3304B

Ejector Truck730C, 740B, 730C2 EJ, 740, 730

Dump Truck773G LRC, 775G, 775F, 775E, 775D, 777C, 777B, 777D, 777G, 777F, 775G OEM, 785, 789, 793, 797, 793B, 793C, 773E, 773D, 773G, 773F, 773B, 769, 773, 777, 775G LRC, 789B, 769B, 769D, 769C, 773G OEM, 785C, 785B

Mining Truck777E, 775D, 775B, 773E, 771D, 771C

Wheel Feller Buncher573C, 553C, 2570C, 563C, 2470C, 2670C

Погрузчик с телескопической стрелойRT80, RT60, RT50, RT100, RTC60, RT50SA

Генераторные установки3304B, 3512, 3306B, C175-16, 3512B, 3406C, 3516C

Wheel Loader960F, 962G, 988B, 966D, 966C, 966F, 966E, G936, 966G, 924K, 926M, 907K, 980, 950G II, 906K, 906M, 988, 994, 990, 992, 920, 980G II, 908K, 908M, 926, 924, 930, 936, 938, 950, 950B/950E, 990K, 990H, 992D, 992B, 992C, 994D, 970F, 972G, 950B, 950E, 950G, 950F, 930K, 930M, 930R, 930T, 936E, 936F, 962G II, 938K, 990 II, 938M, 980F II, 966F II, 980B, 980C, 980F, 980G, 950F II

Load Haul DumpR1300, OTHER, R1300G

Гусеничный трелевщик527, 517, D5HTSK II, D4HTSK III

Двигатель комплекта генератора3406C, 3406B, 3208, 3304B, 3306B, 3306, 3304

Экскаватор с прямой лопатой235C, 385C, 5080, 5090B

Power ModuleXQ2280

Industrial Engine3304, 3306, 3306B, D320A, 3304B, C7.1, 3412, 3406B, 3406C, D333C, D353C, D353E, D353D, D330C

Лесозаготовительное оборудованиеFM528 LL, 538, 548, 558, 568, FM528

Wheel Tractor660B, 641B, 666B, 623B, 623E, 623F, 621B, 621R, 621E, 621F, 621S, 627B, 627E, 627F, 650B, 651B, 651E, 615C II, 631D, 631E, 631C, 613C II, 615, 613, 611, 627, 621, 623, 637, 641, 651, 657, 666, 633C, 657E, 657B, 633D, 657G, 639D, 615C, 613B, 637D, 613C, 637E

Гидравлический мини-экскаватор308E CR, 303.5E2 CR, 308E2, 308E SR, 306E2, 304E2, 304CR, 304C CR, 303C CR, 307.5, 305C CR, 302CR, 305E2 CR, 305E, 304E, 305.5, 308E2 SR, 303.5, 303.5C, 303.5E, 303.5D, 303ECR, 305.5E2, 301.8, 301.9, 307D, 307C, 301.6, 301.5, 307E, 304SR, 308E2CR, 306E, 305.5D, 305.5E, 308E, 308D, 308C, 305.5 GC, 303E CR, 303 SR, 305.5 CR, 308E2 CR, 307E2, 301.7CR, 308E2SR, 305E2, 308.5, 303CR, 304E2 CR, 304D CR, 304, 305, 303, 308, 309, 306, 307, 305.5E2 CR, 304.5E2

Погрузчик бревен для лесозаготовок558

Машина для стабилизации грунтаSS-250B, SS-250

Управление гидросистемой191, 181, 163, 161, 143, 153, 151, 141, 140, 48

Гусеничная валочно-пакетирующая машина1190, 2290, 1390, 2491, 552 2, 541 2, 1290T, 2390, 2391, 2590, 511, 522, 521, 1190T, 521B, 532, 522B, 541, 551, 552

RipperD5, 977, 963, 951, 955, 7, 6, 5, 4, 8

Tractor784C, 784B, 768C, 768B, 772B, 772, 776, 776D, 776C, 776B

Off-Highway Truck777G, 777E, 773GC, 777, 775, 773, D10R

Wheel Dozer834B, 814B, 814F, 844H, 844K, 834, 824B, 844, 824G, 824C, 814, 824G II

Лесозаготовительная машина227

Wheel Scraper666B, 621E, 621F, 621B, 623F, 623B, 623E, 627G, 627F, 627B, 627E, 657G, 633B, 633D, 657E, 657B, 637E, 637G, 613B, 637D, 639D, 615C, 615, 633, 613, 611, 666, 657

Winch57, 56, 55, 528, 518, 57H, 56H

Мини-погрузчик226B, 252B3, 226B3, 272C, 252B, 232B, 236B, 236D, 242B3, 216B, 236, 232, 236B3, 248, 246, 242, 262, 252, 262B, 268B, 216, 242B, 242D, 228, 226, 246B, 248B, 216B3

Оборудование для лесозаготовкиFB221

Форвардер584, 584HD

Вибробрус для асфальта10 FT

Грейфер518, 120C, 125C

Asphalt PaverAP-800, AP-800B, AP-1050, AP-1000

Wheel ExcavatorW330B, W345C MH, M315, M330D, M325C MH, M315GC, MH3040, W345B II

Погрузчик повышенной проходимости267B, 247B, 247B3, 287B, 277B, 257B3, 257D, 257B, 267, 257, 287, 277, 297C, 247

Motor Grader120M 2, 130G, 140K 2, 140M 3, 140M 2, 140H ES, 12M 3 AWD, 12H NA, 140H NA, 160M 3 AWD, 160K, 160H, 160G, 160M, 140M 3 AWD, 16H NA, 14M-3, 12H ES, 14H NA, 120G, 16, 14, 18, 120M, 120K, 140M, 140K, 140H, 140G, 143H, 12M 3, 12M 2, 163H NA, 160M 2, 160M 3, 18M3, 160H ES, 16M, 160, 16G, 14L, 150, 14M, 140, 16GC, 14G, 12H, 12G, 12M, 12K, 14M3, 120, 160H NA, 16M3, 120K 2

Underground Articulated TruckAD60, AD63

Skidder518C, 535B, 528B, 525B, 525, 518, 515, 528, 545, 530B

Mobile Hydraulic Power Unit330D L, 329D L, 365C L, 390F, 330D2, 349D L, 330FMHPU, 385C L, 329E, 336D L, 330 MHPU, 349E L HVG, 325C, 349E, 325D, 345D, 345C, 336E HVG, 324D LN, 349D2, 345C L, 385C, 350MHPU, 352FMHPU, 323F OEM, 336FMHPU, 340D2 L, 325D L, 336F, 336D, 336E, 330F, 330D, 330C, 323D L

Track-Type TractorD6G2 LGP, D8 GC, D4H, D4D, D4E, D5B, D5H, D5E, D6E SR, D6C, D6D, D6R, D6E, D6G, D6H, D6G SR, D6 XE, D4E SR, D6GC, D8GC, D7R, D7G, D7H, D8R, D8L, D8N, D9E, D9G, D6G2 XL, D6D SR, D6H II, D6XE, D4H III, D6F SR, D6, D5, D6H XL, D6H XR, D5H XL, D7G2, D8R II, D4H XL

Коробка передач для нефтяной промышленностиTH48-E70

Гидравлический силовой агрегат от oem-производителя для мобильных судовых систем336MHPU

Коробка передач судового двигателя7271

Погрузчик для бревен345C

Пожарный насосHT400

Landfill Compactor836, 826G II, 816, 826C, 826B, 826G, 816B, 816F

Харвестерная головкаHH44 DE

Машины для регенерации дорожного полотнаRR-250B, RM-350B, RR-250

Самоходная пусковая установка на основе гидравлического экскаватора320E, 352F OEM, 330F OEM

Motor Grader Scarifier140G, 12G, 16G, 130G

Карьерный экскаватор5230B, 5110B, 5230

Soil Compactor815, 815B, 815F, 825G, 825C, 825B

Stabilizer MixerSM-350

Vibratory Soil CompactorCS-323C, CS-433C, CS-653, CS-643, CB-536D, CB-614, CP-643, CP-653, CS-553, CS-551, CP-433C, CP-323C, CB-534, CP-553

Dozer Blade834U, 834S, 6, 8SU, 955, 6SU, 977A, 824S, 825, 7SU, 7S LGP, 8S, 8U, 5A, 5P, 5S, 6A, 6S, 7A, 7S, 7U, 8A, 4A

Articulated TruckD35HP, D30C, D30D, D35C, D250E, D250D, D250B, D300E II, 725C2, D400E, D400D, 730C, 725, 740, 735B, 730, 735 OEM, 735, 725C, 730C2, D20D, D250E II, D25D, D25C, D350E, D350D, D350C, D300E, D300D, D300B, 730 EJECTOR, 740B, D400, D40D

Компактный колесный погрузчик920K, 906H2, 914, 910, 930, 938, 920, 926, 906H, 908M, 908H2, 906M, 907H, 907M, 908H, 910K, 910M, 907H2, 914K, 914M, 918M

Валочно-пакетирующая машинаFB518

Engine - Industrial3406B, 3406C

Integrated ToolcarrierIT62G

Truck Engine1673C, 3306C, 3306B, 3306, 3406C, 3406B, 3208

Excavator330 L, 345B II, 349D L, 215B, 215C, 215D, 324D, 324E, 320D3 GC, 375-A L, 315D L, 320D2, 320D3, 336D2 L, 323F, 374F L, 323D, E300B, 322C, 385C FS, 324E LN, 321C, 345C, 345D, 548, 349F L, 385C L, 219D, 325D L, EL300, 330 LN, 317, 315, 558, 313, 320GX, 374D L, 323F OEM, 336F L XE, 312C L, 323E LN, 314E CR, OTHER, 330C FM, 326F, 320 GX, 538, 349D, 350 L, 336E L, 320 GC, 325C, 349E, 325D, 336E H, 349F, 325F, 340F, 330-A L, 329D LN

Двигатель машины3304, 3306, 3208

Универсальный катокCB2.7, CB2.5, CB2.9, CC2.6

Compact Track Loader299C, 259D, 259B3

Challenger55, 65, 75, 75E, 35, 95E, 45, 70C, 65C, 65B, 65E, 65D, 85E

Гидравлический экскаватор с гидравлическим приводом6040

Погрузчик материаловMH3250, MH3260, MH3032, MH3040, MH3050, MH3295, M325D L MH, M325D MH

Стрела120C

Wheel Tractor-Scraper657, 651

Трубоукладчик587R, 578, 561N, 561M, 561H, 561D, 561C, 583R, 572R, 572G, 571G

Asphalt ReclaimerRM-350B, RM-350, RM-500, RM-250C

Track Loader973C, 951C, 951B, 977D, 977H, 953D, 977K, 977L, 955C, 955H, 955K, 955L, 963, 973, 941, 941B

ГенераторSR4B, SR4
