257-2553: Compactor Wheel Tip Assembly

Description: Part # 257-2553 is a modified chevron tamping tip for the 815 Series Soil Compactor. The symmetrical tamping wheel tip pattern has a modified chevron tamping wheel tip design to provide greater ground pressure, more compaction, a smooth ride, and excellent traction. The tip is welded to a base assembly, which is then welded directly to the drum. Tips are replaceable. The chevron tamping wheel tip design is used for equal compaction in forward or reverse. Attributes: • Hardened steel base with tamping foot tip • Tip Shape: Modified Chevron • Wear/Durability: Standard • Height: 190mm (7.5 in) • Width: 168mm (6.6 in) • Weight: 9.8 kg (21.7 lb) Application: 815 Series Soil Compactor Consult your owner's manual or contact your local Cat Dealer for more information.
