171-3684: Solenoid Valve Cartridge

Description: A Solenoid Valve Cartridge is used in the Selector and Pressure Control Valve unit. It consists of a Solenoid coil, a Valve body, and a Valve plunger. The Valve Body has inlet and outlet ports that allow the fluid to enter and exit the Cartridge. When the Solenoid Coil is energized, the magnetic field attracts the plunger, causing it to move against the Spring or diaphragm, thereby opening or closing the fluid passage. Attributes: • Pressure of fluid can effectively be controlled • Amount of fluid in the unit can effectively be maintained Applications: A Solenoid Valve Cartridge is used to regulate the flow of fluids, this type of Cartridge is mostly used in Cat 1090, 1190, 1190T, 1290T, 1390, 1490, 1490T, 2290, 2390, 2391, 2491, 2590, 511, 511B, 521, 521B, 522, 522B, 532, 533, 541, 543, 551, 552, HA770, HA771, HA870, HA871, TK370, TK371, TK380, TK381, TK711, TK721, TK722, TK732, TK741, TK751, and TK752 Tree Harvester, 135H, 143H, and 163H Motor Grader, 315C, 320, 365, 375, 385, 320C, 322C, 365B, 365C, 365D, 374D, 385B, 385C, 385D, 390D, 5090B, 6015, and 6015B Excavators, 365C, and 385C Material Handler, TR43 Powertrain.
